Superior Cast Iron Water Drain Submersible Pump | 3600 GPH | 1/3 HP | 92359
Pickup, delivery and shipping times are estimates, not guarantees.
Couldn't load pickup availability
● 2 in stock30-day returns Secure checkout
Have a question about this part?
Ask about fit, specs or shipping and get an instant answer.
Goes with this part
CA P65 Warning: Cancer and reproductive harm. www.p65warnings.ca.gov
The Superior Pump 92359 is a 1/3 horsepower submersible sump pump designed for efficient and reliable water removal in various applications. Its continuous-duty, thermally protected split capacitor motor ensures consistent performance, capable of lifting water up to 25 feet vertically. Constructed from rugged cast iron, the pump offers durability and longevity. It features a large 1-1/2-inch discharge port for high-capacity pumping and can function as a utility pump by removing the float switch. Included accessories such as a 3/4-inch garden hose adapter, a 1-1/2-inch barb adapter, and a 25-foot nylon rope enhance its versatility and convenience for various pumping needs.
-
Powerful 1/3 HP Motor: Provides efficient water removal with a vertical lift capacity of up to 25 feet.
-
Durable Cast Iron Construction: Ensures long-lasting performance and reliability in demanding conditions.
-
High-Capacity Pumping: Features a large 1-1/2-inch discharge port for superior water flow.
-
Versatile Utility Pump Option: Float switch can be removed for manual operation as a utility pump.
-
Includes Essential Accessories: Comes with a 3/4-inch garden hose adapter, 1-1/2-inch barb adapter, and a 25-foot nylon rope for easy setup.
- Continuous duty, thermally protected - split capacitor motor
- Pumps will lift water up to 25' of vertical height
- Rugged cast iron construction
- Large 1-1/2" discharge for high capacity pumping
- Can be used as a utility pump by removing the float switch
- 3/4" Garden hose adapter included
- 1-1/2" BARB adapter included
- 25' nylon rope included
-
HP: 1/3
-
Amps: 7.6
-
Construction: Cast Iron
-
Switch Type: Vertical
-
Discharge Size: 1-1/2"
-
Discharge Type: Side
-
Cord Length: 25'
-
Solids Handling: 1/2"
- Impeller Type: Thermoplastic
